Technical Data
Q max: 15 m³/h
H max: 20,5 mWC
From 0,15 kW to 1,1 kW
Voltage: 230V and 3*230/400V
IP54, 50/60 Hz, EN norms, IEC std.
Operating Pressure: 6 bar
Total Suction lift up to 8 m
Connections: G1/2″-G1″-G11/2″
Fluid Temperature: -10 °C to +90 °C

Materials
Full bronze as per EN1982
Stainless Steel shaft, Mechanical Sealed, IE2/IE3 TEFC Motors
Thermal Protection for 230V types

Applications
For moderately dirty liquids or emulsions. For inclustry, agriculture and marine use.
